Features:
HP: 1/3HP-3HP
Pole: 2P, 4P
NEMA design: L
Rolled steel frame, Detachable foot, C flange
Capacitor Start and Capacitor Run
Service factor: 1.15
Insulation Class: F(UL approved)
Enclosure: TEFC
IP Class: IP44
CSA&CUS,UL certified
Accept Manual or Auto Thermal Protector
1. Cixi Waylead Electric Motor Manufacturing Co.,Ltd is located in Cixi City, Zhejiang Province, China, close to the famous international ports Shanghai and Ningbo. The economic and technical conditions are superior, and the transportation is convenient.
2. Cixi Waylead is a professional 56 Frame Four-in-one Motor, Single-Phase Suppliers and 56 Frame Four-in-one Motor, Single-Phase company with rich industry experience. We can make "tailor-made" 56 Frame Four-in-one Motor, Single-Phase according to the requirements of different customers. All our motors are exported to the United States, Canada, Mexico, Japan, Australia, New Zealand, Saudi Arabia, etc. Motors are widely used in woodworking, air compressors, blowers, fans, water pumps, hydraulic pumps, etc.
3. All our oem 56 Frame Four-in-one Motor, Single-Phase and commercial processors have passed CSA & CUS certification, and some motors also have UL certification. The three-phase high-efficiency super-efficiency motor has passed the certification of Canada and the United States Department of Energy in 2007 and 2010.
4. On-site quality and production are managed by "6S". Implement ISO9001 international quality management system standards. Waylead has won the favor of many well-known international buyers with its excellent quality, reasonable price, punctual delivery and good service. Waylead looks forward to working with you in the near future!
|
HP |
RPM |
NEMA |
Model |
Volts |
HZ |
ENCL. |
S.F |
Full Load AMPS |
% |
WGT. |
|
1/3 |
3600 |
56 |
F56C 1/3S2C |
115/230 |
60 |
TEFC |
1.15 |
4.55/2.36 |
67 |
23 |
|
1800 |
56 |
F56C1/3S4C |
115/230 |
60 |
TEFC |
1.15 |
4.99/2.58 |
65 |
24 |
|
|
1/2 |
3600 |
56 |
F56C1/2S2C |
115/230 |
60 |
TEFC |
1.15 |
6.01/3.108 |
68 |
24 |
|
1800 |
56 |
F56C1/2S4C |
115/230 |
60 |
TEFC |
1.15 |
6.68/3.45 |
68 |
25 |
|
|
3/4 |
3600 |
56 |
F56C3/4S2C |
115/230 |
60 |
TEFC |
1.15 |
8.47/4.29 |
74 |
26 |
|
1800 |
56 |
F56C3/4S4C |
115/230 |
60 |
TEFC |
1.15 |
8.27/4.22 |
74 |
29 |
|
|
1 |
3600 |
56 |
F56C1S2C |
115/230 |
60 |
TEFC |
1.15 |
9.44/4.9 |
77 |
30 |
|
1800 |
56 |
F56C1S4C |
115/230 |
60 |
TEFC |
1.15 |
9.7/5.04 |
75 |
38 |
|
|
1.5 |
3600 |
56 |
F56HC1.5S2C |
115/230 |
60 |
TEFC |
1.15 |
13.14/6.77 |
77 |
37 |
|
1800 |
56 |
F56HC1.5S4C |
115/230 |
60 |
TEFC |
1.15 |
3.63/6.66 |
77 |
42 |
|
|
2 |
3600 |
56 |
F56HC2S2C |
115/230 |
60 |
TEFC |
1.15 |
15.3/7.8 |
81 |
44 |
|
1800 |
56 |
F56HC2S4C |
115/230 |
60 |
TEFC |
1.15 |
16.51/8.27 |
80 |
47 |
|
|
3 |
3600 |
56 |
F56HC3S2C |
115/230 |
60 |
TEFC |
1.15 |
24.0/12.3 |
83 |
60 |
56 Frame Four-in-one Motor, Single-Phase is a revolutionary single-phase motor designed for diversified industrial scenarios, perfectly integrating the four-in-one innovative architecture (structure, starting method, protection and certification). Compared with traditional single-phase motors, its core advantage lies in the dual technology of capacitor start + capacitor run, which ensures efficient starting torque and smooth operation, significantly reducing energy consumption and noise. The motor adopts a rolled steel frame and a detachable foot, which takes into account both strength and installation flexibility, while the C-flange design simplifies integration with equipment. The unique high service factor (1.15) and F-class insulation (UL certification) enable it to perform well in harsh environments such as high temperature and dust. It has passed CSA, CUS and UL triple certifications and supports manual/automatic thermal protectors, with safety and compatibility far exceeding similar products. Whether it is a pump, fan, compressor or transmission system, this four-in-one motor redefines the standard of industrial power with its excellent energy efficiency and durability.
56 Frame Four-in-one Motor, Single-Phase is a revolutionary single-phase motor designed for diversified industrial scenarios, perfectly integrating the four-in-one innovative architecture (structure, starting method, protection and certification). Compared with traditional single-phase motors, its core advantage lies in the dual technology of capacitor start + capacitor run, which ensures efficient starting torque and smooth operation, significantly reducing energy consumption and noise. The motor adopts a rolled steel frame and a detachable foot, which takes into account both strength and installation flexibility, while the C-flange design simplifies integration with equipment. The unique high service factor (1.15) and F-class insulation (UL certification) enable it to perform well in harsh environments such as high temperature and dust. It has passed CSA, CUS and UL triple certifications and supports manual/automatic thermal protectors, with safety and compatibility far exceeding similar products. Whether it is a pump, fan, compressor or transmission system, this four-in-one motor redefines the standard of industrial power with its excellent energy efficiency and durability.
B. Detailed product introduction
Core advantages and unique parameters
Four-in-one design Structure (rolled steel frame + removable base + C flange) + capacitor dual-mode start + IP44 protection + multiple certification integration
Capacitor start and operation Dual capacitors work together: high torque in the start phase, high efficiency in the operation phase, 15% reduction in energy consumption vs ordinary single-phase motors
Protection and durability TEFC (totally enclosed fan cooling) housing + IP44 protection (dust and water proof), suitable for humid and dusty environments
Safety certification UL, CSA, CUS triple certification, global compliance
Thermal protection system supports manual or automatic thermal protector (automatic power off in case of overload)
Service factor 1.15 (stronger overload operation capability)
General technical parameters
Power (HP) 1/3HP, 1/2HP, 3/4HP, 1HP, 1.5HP, 2HP, 3HP
Pole number (Pole) 2P (high speed), 4P (high torque)
Insulation level Class F (UL certified, 155°C high temperature resistant)
Frame type NEMA L design (compatible with industrial standard interfaces)
Application scenarios
✅ Industrial equipment: compressors, pumps, conveyor belts, fans
✅ Agricultural machinery: irrigation systems, crushers
✅ Commercial equipment: air conditioning condensers, refrigeration systems
✅ Construction equipment: elevators, mixers
