Features:
HP: 1/3-10HP
Pole: 2P, 4P
Frame: 56-215T
Enclosure: TEFC
IP Class: IP44
Service Factor: 1.15
Capacitor Start and Capacitor Run
Accept C-face Kit
Accept Manual or Auto Thermal Protector
CSA&CUS,UL certified
|
HP |
RPM |
NEMA |
Model |
Volts |
HZ |
ENCL. |
S.F |
Full Load AMPS |
WGT. |
|
1/3 |
3600 |
56 |
F56 1/3S2C |
115/208-230 |
60 |
TEFC |
1.15 |
4.55/2.19-2.36 |
23 |
|
1800 |
56 |
F56 1/3S4C |
115/208-230 |
60 |
TEFC |
1.15 |
4.99/2.31-2.58 |
23 |
|
|
1/2 |
3600 |
56 |
F56 1/2S2C |
115/208-230 |
60 |
TEFC |
1.15 |
6.01/3.06-3.11 |
24 |
|
1800 |
56 |
F56 1/2S4C |
115/208-230 |
60 |
TEFC |
1.15 |
6.68/3.11-3.45 |
25 |
|
|
3/4 |
3600 |
56 |
F56 3/4S2C |
115/208-230 |
60 |
TEFC |
1.15 |
8.47/4.18-4.29 |
26 |
|
1800 |
56 |
F56 3/4S4C |
115/208-230 |
60 |
TEFC |
1.15 |
8.27/4^.22 |
29 |
|
|
1 |
3600 |
56 |
F56 1S2C |
115/208-230 |
60 |
TEFC |
1.15 |
9.44/5.06^.9 |
30 |
|
1800 |
56 |
F56 1S4C |
115/208-230 |
60 |
TEFC |
1.15 |
9.7/4.89-5.04 |
38 |
|
|
1800 |
143T |
F143T1S4C |
115/208-230 |
60 |
TEFC |
1.15 |
9.3/5.18-4.78 |
40 |
|
|
1.5 |
3600 |
56 |
F56 1.5S2C |
115/208-230 |
60 |
TEFC |
1.15 |
13.14/7.33-6.77 |
38 |
|
1800 |
56 |
F56 1.5S4C |
115/208-230 |
60 |
TEFC |
1.15 |
13.63/7.09-6.66 |
43.8 |
|
|
1800 |
145T |
F145T1.5S4C |
115/208-230 |
60 |
TEFC |
1.15 |
13.3/7.1-6.6 |
45 |
|
|
2 |
3600 |
145T |
F145T1.5S2C |
115/208-230 |
60 |
TEFC |
1.15 |
13.1/7.0-6.6 |
40 |
|
3600 |
56 |
F56 2S2C |
115/208-230 |
60 |
TEFC |
1.15 |
15.3/8.48-7.8 |
44 |
|
|
1800 |
56 |
F56 2S4C |
115/208-230 |
60 |
TEFC |
1.15 |
16.51/9.08-8.27 |
47 |
|
|
1800 |
145T |
F145T2S4C |
115/208-230 |
60 |
TEFC |
1.15 |
16.51/9.08-8.27 |
55 |
|
|
3 |
3600 |
145T |
F145T2S2C |
115/208-230 |
60 |
TEFC |
1.15 |
16.5/9.2-8.4 |
50 |
|
3600 |
56 |
F56 3S2C |
115/208-230 |
60 |
TEFC |
1.15 |
24.0/13-12.3 |
62 |
|
|
3600 |
145T |
F145T3S2C |
115/208-230 |
60 |
TEFC |
1.15 |
24.0/13-12.3 |
67 |
|
|
1800 |
182T |
F182T3S4A |
208-230/460 |
60 |
TEFC |
1.15 |
14.5-12.55/6.35 |
91.5 |
|
|
5 |
3600 |
184T |
F184T5S2A |
208-230/460 |
60 |
TEFC |
1.15 |
22.95-19.75/10 |
95 |
|
1800 |
184T |
F184T5S4A |
208-230/460 |
60 |
TEFC |
1.15 |
23.4-20.3/10.3 |
110 |
|
|
7.5 |
1800 |
213T |
F213T7.5S4A |
208-230/460 |
60 |
TEFC |
1.15 |
33.8-29.5/14.86 |
153 |
|
10 |
1800 |
215T |
F215T10S4A |
208-230/460 |
60 |
TEFC |
1.15 |
43-37.8/18.9 |
190 |
